Chlorotrifluoro Ethylene (CTFE)
Chlorotrifluoro Ethylene (CTFE, R1113, CFC 1113, Trifluorochloroethylene) is the organic compound with the formula CF2CFCl. The CTFE is colorless gas at normal temperature and poisonous, and the liquefied CTFE is colorless and transparent. It has extremely unstable chemical properties and is combustible. It is mainly applied to fluoroelastomer, fluorine paintings, chlorofluorocarbon oil, isoflurane, anesthetics for animals, pesticide intermediates, etc.
Chlorotrifluoroethylene is produced commercially by the dechlorination of 1,1,2-trichloro-1,2,2-trifluoroethane with zincin methanol. In 2012, an estimated 1-10 million pounds were produced commercially in the United States.
Package & Transport
Package Size: 1000KG; 17 T
UN Number: 1082
Hazard Class: 2.1, 2.3
1. Store in a cool, well-ventilated area of low fire risk and out of direct sunlight.
2. Cylinders should be stored upright and firmly secured to prevent falling or being knocked over. Valve protection caps and valve cutlet threaded plugs must remain in place unless container is secured with valve outlet piped to use point. Do not drag, slide or roll cylinders.
3. Separate full containers from empty containers.
4. Avoid area where salt or other corrosive materials are present.
5.Avoid excessive inventory and storage time.
|Molecular formula||C2F3Cl (CF2CFCl)|
|Molar mass||116.48 g/mol|
|Jmol-3D images||Image 1|
|Odor||faint etheral odor|
|Density||1.54 g/cm3 at -60℃|
|Melting point||-158.2℃ (124.95 K)|
|Boiling point||-27.8℃ (245.35 K)|
|Vapour pressure||612 kPa at 25℃|
|Refractive index(nD)||1.38 (0℃)|
|Solubility in water||40.1 g/L|
|Solubility||soluble in benzene, chloroform|
